Technical Specifications
-
Scanner Parameters
Product Model : BW-3270
Item : 1D Wired/Wireless ,2D Wired/Wireless
Physical Parameter
Material : ABS+PVC+PC
Power Supply : Charging DC 5V ±5% ;inside 3.7V 2000mA lithium battery
Electric Current : 0.37W(working); 0.16W(standby); 0.71W(maximum)
Weight : 146g±5g(Without cable)
Size : L*W*H:196 * 87 * 70(unit/mm)
Color : black, grey
Button use >: 10w times
Performance Parameter
Interface : USB;wireless 2.4G
System Supported : Linux,Android,Windows XP、7、8、10,MAC
Language Supported : English; German; French; Spain; Italian; Japanese (supports virtual keyboards)
Sensor : Planar CMOS sensor
Light Source : Red led aiming + white led lighting
Processor : 32-bit ARM MCU
Storage : 64K (Can be customized)
Motion Tolerance : Code128: 15cm/sec
QR: 25cm/sec
Resolution : 4 Mil
Wireless transmission distance : 90m Visible distance
Bit Error Rate : 1/5000000
Reading mode : Image
Trigger Mode : Manual ;Continuous scanning
Prompt Mode :Buzzer, Indicator Light(LED -
Print Contrast : 35%
Charging time : appr.8h
working time : appr.42h
Decoding
Capability :
● Code25-Interleaved ● Code25-Standard ● Code25-Matri
● Code39-Regular ● Code39-FullASCII ● Code32
● Code93-Regular ● Code93-FullASCII ● Code128
● EAN/GSL/UCC-128Auto ● Codabar ● MSI
● EAN/JAN-13 ● UPC-A ● JAN-8
● Code11 ● UPCE0
● Data Matrix ● QR ● PDF417 ● Micro QR ●HanXin
● Micro PDF 417 ● Maxi Code ●Aztec
1D
2D
Scanning Distance : 10mm-600mm
Scanning Angle : Pitch±65°,Yew±55°,Roll 360°
Scanning depth : Code39 5mil:5cm - 8cm
QR 20mil:4cm - 25cm
Environment Parameter
IP Grade : IP52
Operating Temp. : 0 to 50℃/ 32 to 122℃
Storage Temp. : 0 to 50℃ / 32 to 122℉
Operating Humidity : 20% to 85%(No Condensation)
Storage Humidity : 20% to 85%(No Condensation)
ESD Protection : 15KV air discharge
Shock Resistance : 1.2m free fall on concrete surface
